Radial electrolytic capacitor, 1.0 µF, 50 V, RM 2.0
NEW
Ripple current(mA rms) 85°C 100kHz: 22,1 mA
D x L: 5 x 11 mm
High reliability withstanding 2000 hours load life at 85°C
spacing: 2.0 mm
Operating temperature range: -40 ~ +85°C
Leakage current max. I = 0.01CV or 3µA whichever is greater (after 2 minutes)
Capacitance tolerance: ±20% at 120Hz, 20°C
Part-Number: 860020672005
860020672005.pdf
D x L: 5 x 11 mm
High reliability withstanding 2000 hours load life at 85°C
spacing: 2.0 mm
Operating temperature range: -40 ~ +85°C
Leakage current max. I = 0.01CV or 3µA whichever is greater (after 2 minutes)
Capacitance tolerance: ±20% at 120Hz, 20°C
Part-Number: 860020672005
860020672005.pdf
