A6966G-G09-T 5 DOT LED LEVEL METER
The UTC A6966 is designed for 5 LED level meter driver in 9 lead
SIP package. It consists of one input amplifier and five comparators
for LED level indication.
• Low Spurious Noise Operation.
• Constant Current Output: IOUT=8mA (Typ.)
• Indication Level Steps: 5dB, 5dB, 3dB, 3dB
• Wide Operating Supply Voltage Range: VCC = 4~ 12V
• Variable Input Amplifier Gain: GV = 0 ~ 20dB
